CEB Mocap MPP2SOS

Download for free using the code: B7GKDN2

Works only on Windows

Important: This tool is NOT easy to use at first. Probably you wont be able to make it work at the first time, but I'll be available to help you to get it working. For that we have this discord channel https://discord.gg/BRuu43Nv2J

Attention: This addon currently doenst work with launchers. If you get an error when executing it, use the zip file distributed in blender.org

This addons aims to make the process of creating mocap data from video much easier and everything is done inside of www.blender.org

If you want to have more information of this addon, you can see out patreon: https://www.patreon.com/cebstudios

It is a pack of OpenCV+MediaPipe+Pose2Sim and OpenSim.

Example of the result from MOCAP MPP2SOS done by AK3Dfx

0.042 New Feature

Full Workflow using version 0.040

Full workflow using version 0.032

Retarget using Autorig Pro

Retarget using Rokoko

Flipping animation

On the addon you have camera calibration management, so you dont have to calibrate again a set of cameras on a scene you already did.

Easy to use intrinsic calibration menu

An easy to use extrinsic calibration tool and a set of tool to manually configura that challenging shot where the automatic on didnt do so well.

Use the power of Mediapipe, Pose2Sim and OpenSim under the hood, all integrated in an single addon, where you dont have to download anything else.

This addon was possible with the help of the following tools

• Full calibration (intrinsic and extrinsic)
• Project management (you can reuse calibration already done)
• Pose estimation (powered by Mediapipe)
• Pose triangulation (powered by Pose2Sim)
• Animation Filtering (powered by Pose2Sim)
• OpenSim configuration (powered by Pose2Sim)
• Solvers for realistic biped walking (powered by OpenSim)


If you like to get in contact, send a message at our patreon

https://www.patreon.com/cebstudios

or via twitter

https://twitter.com/carlosedubarret

Update log:

0.11 - Added flip option on the imported animation data

0.10 - Originally it was going to be called 0.045, but there were so many things to update that the correct would be to proper call it 0.10 😃

• save the intrinsic settings,
• save prj settings and autoload then
• Option to open calib folder with calib data
• Added visual information to make easy to know what is missing (red alerts)
• Fixed the error that showed on console when checking Cross (Extrinsic calibration)
• When calibration, the next and prev cams now automatically clear the markers, load the video and go to first frame (for intri and extri calib)
• if no marker created on extrinsic, it will render the first frame
• option to create pose annotation images (Mediapipe option)
• Option to use segmentation mask when creating annotation images (Mediapipe option)
• removed the instruction links (it was not needed anymore as the addon incorporates calibration)
• Go to first camera after saving the videos (so when the user gets to the frame selection, he wont need to go to the camera 1 manually)
  • Also clear markers when click on save on the Extrinsic video set
• Change camera to the first one when changing "Tabs" (Last/Next buttons on botton/top)


0.044 -Added option to invert calibration orientation and fix error when using the project whit space on the name

0.043 - Fix: using project folder with spaces gave erro when using opensim pass
0.042 - Better way to do the manual calibration
